Knock Sensor, Remove and Install
Detach wiring plug connection for knock sensor and unscrew knock sensor with KM-728-A from cylinder block.
Bolt knock sensor with KM-728-A (1) to cylinder block. Connect wiring plug connection for knock sensor.
The recommended torque value must be observed; otherwise malfunctions may occur. The recommended torque value is attained before the knock sensor contacts the cylinder block fully.
| Knock sensor to cylinder block (M8) | - 20 Nm / 15 lbf. ft. |
|---|---|
| Knock sensor to cylinder block (M10) | - 12.5 Nm / 9 lbf. ft. |
