Components
Corsa-B, X 14 SZ
- Y34 Valve-Fuel Tank Ventilation 4 P23 Sensor-Absolute Pressure, Intake Manifold
- M66 Actuator-Idle Speed 5 L2 Ignition Coil-Direct Ignition
- Y18 Solenoid Valve-Exhaust Gas Recirculation 6 P33 Sensor-Oxygen, Exhaust
Corsa-B, Tigra, X 14 XE, X 16 XE
| 1 | Intake Manifold |
|---|---|
| 2 | P23 Sensor-Absolute Pressure, Intake Manifold |
| 3 | M27 Pump-Secondary Air Induct |
| 4 | Filter Secondary Air |
| 5 | L2 Ignition Coil-Direct Ignition |
| 6 | Valve Secondary Air |
| 7 | P30 Temperature Sensor-Coolant |
Astra-F, X 14 XE
The X 14 XE engine which was already introduced in the Tigra/Corsa-B is now also used in the Astra-F. The only difference from the Tigra/Corsa-B version is a more voluminous central sucking intake manifold (1). Component locations are identical to the Tigra/Corsa-B X 14 XE.
Astra-F, X 16 XEL
| 1 | P29 Temperature Sensor-Intake Manifold | 4 | L2 Ignition Coil-Direct Ignition |
|---|---|---|---|
| 2 | P23 Sensor-Absolute Pressure, Intake Manifold | 5 | P33 Sensor-Oxygen, Exhaust |
| 3 | Y34 Valve-Fuel Tank Ventilation | 6 | P30 Temperature Sensor-Coolant |
Astra-F, X 16 XEL
| 1 | P34 Potentiometer-Throttle Valve | 5 | P35 Impulse Sensor-Crankshaft |
|---|---|---|---|
| 2 | M66 Actuator-Idle Speed | 6 | P46 Sensor-Knocking Control |
| 3 | Pressure Regulator, Fuel | 7 | Y18 Solenoid Valve-Exhaust Gas Recirculation |
| 4 | P47 Sensor-Camshaft | ||
