Replace Secondary Air System Pump Opel Vectra C

Remove

1. 1. Open bonnet
2. 2. Disconnect battery.
3. 3. Raise vehicle by its entire height
4. 4. Remove secondary air system pump (4) • Disconnect wiring harness plug (2) • Detach 2 secondary air hoses (1) – Undo 2 quick-release fittings • Unclip coolant hose • Separate cable tie • Unscrew 2x bolt (3)

5. 5. When replacing secondary air system pump, remove secondary air system pump bracket • Unscrew 3x nut • Unclip wiring harness plug from bracket

Install

6. 6. Attach secondary air system pump bracket • Tighten 3x nut • Clip wiring harness plug into bracket.
7. 7. Install secondary air system pump • Attach cable ties • Clip coolant hose into bracket • Fasten 2 quick-release fittings • Tighten 2x bolt • Connect wiring harness plug
8. 8. Lower vehicle by its entire height
9. 9. Connect battery.
10. 10. Program volatile memories
11. 11. Close bonnet
