"Neutral torque axis engine suspension (NTA engine suspension)" is used for all Vectra-C engine versions. The function corresponds to that of the systems in the Corsa-C, Astra-G and Zafira, but has been optimised.
The use of the NTA engine suspension as well as the body-insulated front axle body, optimally reduces the transmission of noise and vibration to the passenger compartment.
The engine's load change reactions are absorbed by a reaction members (rubber mounts) at the front and rear of the front axle body.
The engine / transmission mountings consist of two hydraulically-functioning rubber mounts:
- On the engine timing side, the rubber mount is bolted vertically to the upper right frame side member.
- The second rubber mount is fastened to the left frame side member and is bolted vertically to the transmission housing.
• Service:
Assembly operations must only be performed in conjunction with the specified special service tools
- KM-904 Retainer Frame
- KM-6312 Centring Equipment
- KM-6313 Engine / Transmission Mount
Their application is described in the "Service Instructions" in group "J".
- 1. Engine damping block, left
- 2. Neutral torque axis (NTA)
- 3. Engine damping block, right
- 4. Reaction member, rear
- 5. Reaction member, front
