Terminal Assignment
Terminal Assignment of Control Unit, Vectra-B
- X13 Diagnostic Link 16P 27 P30 Temperature Sensor-Coolant
- Ground (Terminal 31) 29 Ground (Terminal 31)
- K85 Control Unit-Automatic Transmission 30 P46 Sensor-Knocking Control
- K85 Control Unit-Automatic Transmission 31 P47 Sensor-Camshaft
- K50 Control Unit-ABS K95 Control Unit-ABS & TC K117 Control Unit-Immobiliser 32 P47 Sensor-Camshaft (Ground)
- K85 Control Unit-Automatic Transmission 33 P44 Air Mass Meter
- Ground (Terminal 31) 34 K60 Relay-Compressor, Air Conditioning (Ground)
- P29 Temperature Sensor-Intake Air 35 K43 Relay-Injection Valves
- S20 Switch ASM-Pressure 36 P32 Sensor-Oxygen Exhaust, heated
- P32 Sensor-Oxygen Exhaust, heated 38 L2 Ignition Coil-Direct Ignition (Ground)
- Ground (Terminal 31) 39 L2 Ignition Coil-Direct Ignition (Ground)
- P46 Sensor-Knocking Control 40 Y7 Injection Valve 4-Fuel (Ground)
- P47 Sensor-Camshaft 41 Y7 Injection Valve 2-Fuel (Ground)
- P44 Air Mass Meter (Ground) 42 Y7 Injection Valve 1-Fuel (Ground)
- Ground (Terminal 31) 43 Y7 Injection Valve 3-Fuel (Ground)
- P35 Impulse Sensor-Crankshaft 44 M33 Actuator-Idle Speed
- Ignition ON (Terminal 15) 45 Y18 Solenoid Valve-Exhaust Gas Recirculation (Ground)
- P34 Potentiometer-Throttle Valve 46 M33 Actuator-Idle Speed
- Ground (Terminal 31) 47 Y34 Solenoid Valve-Tank Ventilation (Ground)
- P7 Tachometer 48 P32 Sensor-Oxygen Exhaust, heated (Ground)
- U15 Display-TID U16 Display-MID 49 K43 Relay-Injection Valves (Ground)
- X13 Diagnostic Link 16P 50 Y15 Solenoid Valve-Secondary Air Induct (Ground)
- S20 Switch ASM-Pressure 52 H30 Telltale-Engine (Ground)
- P35 Impulse Sensor-Crankshaft (Ground) 53 Y19 Solenoid Valve-Intake Manifold (Ground)
- K50 Control Unit-ABS K95 Control Unit-ABS & TC 54 K44 Relay-Fuel Pump (Ground)
- P34 Potentiometer-Throttle Valve 55 Battery Voltage (Terminal 30)
Terminal Assignment of Control Unit, Omega-B
| | | |
|---|
| 1 | X13 Diagnostic Link 16P | 27 | P30 Temperature Sensor-Coolant |
| 2 | Ground (Terminal 31) | 29 | Ground (Terminal 31) |
| 3 | K85 Control Unit-Automatic Transmission | 30 | P46 Sensor-Knocking Control |
| 4 | K85 Control Unit-Automatic Transmission | 31 | P47 Sensor-Camshaft |
| 5 | U4 Hydroaggregat ASM-ABS K118 Control Unit-Immobiliser | 32 | P47 Sensor-Camshaft (Ground) |
| 6 | K85 Control Unit-Automatic Transmission | 33 | P44 Air Mass Meter |
| 7 | Ground (Terminal 31) | 34 | K60 Relay-Revolution, Compressor, AC (Ground) |
- P29 Temperature Sensor-Intake Air 35 K43 Relay-Injection Valves
- S109 Switch-Revolution Acceleration 36 P32 Sensor-Oxygen Exhaust, heated (Ground)
- P32 Sensor-Oxygen Exhaust, heated 38 L2 Ignition Coil-Direct Ignition (Ground)
- Ground (Terminal 31) 39 L2 Ignition Coil-Direct Ignition (Ground)
- P46 Sensor-Knocking Control 40 Y7 Injection Valve 4-Fuel (Ground)
- P47 Sensor-Camshaft 41 Y7 Injection Valve 2-Fuel (Ground)
- P44 Air Mass Meter (Ground) 42 Y7 Injection Valve 1-Fuel (Ground)
- Ground (Terminal 31) 43 Y7 Injection Valve 3-Fuel (Ground)
- P35 Impulse Sensor-Crankshaft 44 M33 Actuator-Idle Speed
- Ignition ON (Terminal 15) 45 Y18 Solenoid Valve-Exhaust Gas Recirculation (Ground)
- P34 Potentiometer-Throttle Valve 46 M33 Actuator-Idle Speed
- Ground (Terminal 31) 47 Y34 Solenoid Valve-Tank Ventilation (Ground)
- P7 Tachometer 48 P32 Sensor-Oxygen Exhaust, heated (Ground)
- U15 Display-TID U16 Display-MID 49 K43 Relay-Injection Valves (Ground)
- X13 Diagnostic Link 16P 50 Y15 Solenoid Valve-Secondary Air Induct (Ground)
- S20 Switch ASM-Pressure 52 H30 Telltale-Engine (Ground)
- P35 Impulse Sensor-Crankshaft (Ground) 54 K44 Relay-Fuel Pump (Ground)
- P34 Potentiometer-Throttle Valve 55 Battery Voltage (Terminal 30)
