Note. When dismantling/assembling some components it is necessary to release or fasten internal wedge profile bolts (RIBE CV). The relevant screwdriver inserts should be purchased on the open market for this purpose.
| KM-161-B | Remover |
|---|
| Pushing tie rod joint out of steering knuckle |
| KM-301 | Measuring Bridge |
|---|
| Measuring the piston projection |
| KM-313 | Slide Hammer |
|---|
| To remove axle shafts in conjunction with KM-902 |
| KM-328-B | Extractor |
|---|
| To extract various bearings and plugs |
| KM-412-A | Engine Overhaul Stand |
|---|
| To hold removed engine |
| KM-412-36 | Engine adapter |
|---|
| Engine mounting in conjunction with KM-412-A |
| KM-468-B | Holding Wrench |
|---|
| To counterhold wheel hub |
| KM-470-B | Angular Torque Wrench |
|---|
| Tightening screwed joints by applying torque |
| KM-471 | Adapter |
|---|
| To check cooling system under pressure in conjunction with cooling system tester |
| KM-498-B | Oil Pressure Gauge |
|---|
| To check engine oil pressure |
| KM-507-C | Remover |
|---|
| Pushing tie rod joint out of steering knuckle |
| MKM-558-10 | Closure cover |
|---|
| Close brake fluid reservoir |
| MKM-596-A | Temperature Gauge |
| MKM-604-D | Torx Bit and Socket Set |
|---|
| Removal, installation of Torx bolts, nuts |
| MKM-610 | Torque Wrench 1/2" |
|---|
| Range 30 – 130 Nm |
| MKM-611 | Torque Wrench 3/8" |
|---|
| Range 10 – 60 Nm |
| MKM-669 | Torque Wrench 1/2" |
|---|
| Range 50 – 300 Nm |
| KM-796-A | Installation Clamp |
|---|
| To open quick-release fittings for fuel system |
| KM-807 | Closure Plugs |
|---|
| To seal off fuel lines |
| MKM-883-2 | Adapter Plate |
|---|
| Holding the engine in conjunction with MKM-883-1 and MKM-883-3 |
| KM-902 | Remover |
|---|
| To remove axle shafts in conjunction with KM-313 |
| KM-904 | Base Frame |
|---|
| To remove/install engine and transmission with KM-6312 |
| KM-956 | Holding Wrench |
|---|
| KM-956-1 from this | Counterholding the belt pulley/crankshaft |
| KM-2358 | Wire Cable |
|---|
| To suspend engine |
| KM-6015 | Closure Plugs |
|---|
| Sealing off fuel lines |
| KM-6349 | Locating pin |
|---|
| To fasten Ribbed V-belt tensioner |
| KM-6182-1 | Pliers, straight |
|---|
| Removal/installation of compact clamps |
| KM-6182-2 | Pliers, curved |
|---|
| Removal/installation of compact clamps |
| KM-6182-3 | Pliers, flexible shaft |
|---|
| Removal/installation of compact clamps |
| KM-6263 | Remover and installer |
|---|
| Removing and installing all clutches |
| KM-6282 | Remover |
|---|
| To remove drive shafts out of wheel flange |
| KM-6312 | Centring Tool |
|---|
| Vehicle underbody, with KM-904 and hydraulic jack |
| KM-6313 | Engine/Transmission Mount |
| KM-6313-100 | Engine support for KM-6313 |
|---|
| To support engine when working on the engine timing side and for removing/installing engine |
| KM-6327 | Adapter |
|---|
| To seal off coolant compensation tank for leak testing cooling system, with KM-471 |
| KM-6347 | Bracket |
|---|
| Holding the camshaft sprockets to release them |
| Tightening the fastening bolts in conjunction with KM-956-1 |
| MKM-J-6459-B | Torque Wrench 3/8" |
|---|
| Range 0 – 11 Nm |
| MKM-6600-1 | Torque wrench 4-40 Nm |
|---|
| Small torque wrench with low torque range for use in constricted areas, in conjunction with MKM-6600-100, MKM-6600-200 and MKM-6600-300 |
| MKM-6600-2 | Torque wrench 20-120 Nm |
|---|
| Large torque wrench with high torque range for use in constricted areas, in conjunction with MKM-6600-100, MKM-6600-200 and MKM-6600-300 |
| MKM-6600-100 | Open-ended Torx wrench set |
|---|
| Size: E8, E10, E11, E12, E14, E16, E18, E20, E22, E24 for use in constricted areas, in conjunction with MKM-6600-1 and MKM-6600-2 |
| MKM-6600-200 | Open-ended ring spanner set |
|---|
| Sizes: 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27 for use in constricted areas, in conjunction with MKM-6600-1 and MKM-6600-2 |
| MKM-6600-300 | Open-ended spanner set |
|---|
| Sizes: 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27 for use in constricted areas, in conjunction with MKM-6600-1 and MKM-6600-2 |
| MJM-J-37228 | Separation Tool |
|---|
| Detaching the oil pan |
| KM-J-41623-B | Release tool |
|---|
| Releasing fluid cooler line at radiator |
| EN-46783 | Adapter |
|---|
| For checking compression in conjunction with EN-46791 |
| EN-46786 | Remover |
|---|
| To remove injectors in conjunction with KM-328-B |
| EN-46787 | Bracket |
|---|
| Holding the camshaft sprocket to release/tighten the fastening bolt in conjunction with KM-956-1 |
| EN-46788 | Fixing tool |
|---|
| To fix crankshaft sprocket in position |
| EN-46790 | Remover |
|---|
| Removing the drive wheel for the high pressure diesel fuel pump |
| EN-46792 | Flywheel Holder |
|---|
| To lock flywheel or drive disc |
| EN-46793 | Installer |
|---|
| Installing oil pump seal ring, crankshaft |
| EN-46794 | Socket Wrench |
|---|
| Removing/installing the oil pan bolts on the transmission side |
| EN-46796 | Socket Wrench |
|---|
| Removing/installing the oil pan bolts |
| EN-46797 | Tool for holding down valve |
|---|
| Pressing down the valve lifter in conjunction with EN-46799 |
| EN-46799 | Fixing tool |
|---|
| Fixing the valve lifter in the lower position in conjunction with EN-46797 |
| EN-47631 | Socket wrench, short |
|---|
| Removing/installing the oil pan bolts via subframe |
| EN-47632 | Cleaner |
|---|
| Cleaning the injector shaft |
| EN-47655 | Injector diagnostic tool |
|---|
| Checking the injectors on Common Rail diesel engines (Bosch injectors only) |
| EN-47656-1 | Pressure test plug - connectors |
|---|
| Checking for leaks in the charge-air system in conjunction with tyre inflator |
| EN-47656-2 | Pressure test plug |
|---|
| Checking for leaks in the charge-air system in conjunction with tyre inflator |
| EN-48389 | Remover/Installer |
|---|
| Removing/installing the glow plugs, width 10 mm |
| MKM-6627 | RIBE - Socket wrench kit |
|---|
| Removal/installation of all bolts using RIBE head interlocking . Size: 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 21, 22, 24, 27, Length: 30mm and 75mm |
