Replace Camshaft (Front) Seal Ring Opel Vectra C

1. 1. Remove toothed belt
2. 2. Detach camshaft sprocket • Remove bolt (2) • Use EN-46787 (1) and KM-956-1

Important. Do not damage camshaft sensor (arrow) when counterholding.

3. 3. Remove camshaft seal ring (1) • Lever out seal ring

Important. Do not damage sealing surfaces.

Install

4. 4. Install camshaft seal ring • Use EN-46793 (2) • Drive seal ring (1) in flush

5. 5. Attach camshaft sprocket • Bolt 120 Nm • Use EN-46787 and KM-956-1

Important. Do not damage camshaft sensor when counterholding.

6. 6. Install toothed belt
