Replace Right-Hand Engine Damping Block Opel Astra H

Remove

1. 1. Remove air filter housing with mass air flow meter • Detach mass air flow meter wiring harness plug (3) • Detach air intake hose from air intake pipe – Release clamp (2) • Unscrew bolt (1)

2. 2. Raise vehicle
3. 3. Remove right engine splash guard (2) • Unscrew 4x bolts (1) • Remove 2x body-bound rivets (3)

4. 4. Attach KM-6173 (3) to front axle body • Raise support bearing (2) until journal sits flush in mount (1) on cylinder block

5. 5. Slacken fastening bolts (arrows) for adjusting rails at KM-6001-A (1)
6. 6. Insert KM-6001-A as shown

Note. The journals (2) and (5) must sit in the guide holes of the front axle body

7. 7. Tighten fastening bolts for adjustment rails.
8. 8. Screw up front support bearing (4) and rear support bearing (3) until they rest against front engine damping block guide journals and rear engine damping block bracket

Note. Guide journals must rest in support bearings without play

9. 9. Lower vehicle
10. 10. Detach engine damping block (2) from engine damping block support • Unscrew 3x bolts (1)

11. 11. Detach engine damping block from side member • Unscrew 3 bolts
12. 12. Remove engine damper block

Install

13. 13. Insert engine damping block
14. 14. Attach engine damping block to side member 35 Nm • Screw in 3x bolts
15. 15. Attach engine damping block to engine damping block support 55 Nm • Screw in 3x bolts
16. 16. Install air cleaner housing with mass air flow meter • Insert air cleaner housing • Attach air intake hose to air intake pipe – Fasten clamp • Screw in bolt • Connect mass air flow meter wiring harness plug
17. 17. Raise vehicle
18. 18. Detach KM-6173 from front axle body
19. 19. Detach KM-6001-A from front axle body
20. 20. Install right engine splash guard
