| No. | Designation | Note | Fastening | Tightening torque |
|---|---|---|---|---|
| 1 | Rear engine damping block | At front axle body | Bolt connection/nut | 55 Nm |
| 2 | Rear engine damping block bracket | to transmission | Bolt connection | 80 Nm |
| to engine damping block | Nut | 55 Nm | ||
| 3 | Left engine damping block to side member | Remove battery support. Detach left engine damping block from engine damping block support Detach engine damping block support from transmission Remove left engine damping block | 4x bolts | 20 Nm |
| Left engine damping block to left engine damping block support | 3x bolts | 55 Nm | ||
| Left engine damping block support to transmission | 3x bolts | 65 Nm | ||
| 4 | Front engine damping block | 2x bolts | 80 Nm | |
| Bolt connection | 55 Nm | |||
| 5 | Right engine damping block to side member | Remove air cleaner housing | 3x bolts | 35 Nm |
| 6 | Right engine damping block to right engine damping block support | 3x bolts | 55 Nm |
- 1. When replacing the left and right engine damping blocks, the engine must be suspended from an engine hoist • Attach engine hoist to corresponding engine transport shackle
