Replace Air Intake Pipe Opel Astra H

Remove

1. 1. Unscrew bolt (2)
2. 2. Remove engine vent hose from cylinder head cover • Release clamp (4)
3. 3. Detach air intake pipe from air intake hose • Release clamp (1) – Release clamp
4. 4. Detach air intake pipe from turbocharger • Release clamp (3)

Note. Seal air intake pipe at turbocharger

5. 5. Remove air intake pipe

Install

6. 6. Remove seal from turbocharger air intake pipe
7. 7. Attach engine vent hose to cylinder head cover • Fasten clamp
8. 8. Attach air intake pipe to turbocharger • Fasten clamp
9. 9. Attach air intake pipe to air intake hose • Fasten clamp
10. 10. Screw in bolt
