Replace Both Oil Leak Lines Opel Vectra C

Important: Extreme cleanliness is important when working on the fuel system, since even minute dirt particles can cause engine or fuel system problems. Open fuel connections must be sealed with suitable sealing plugs from the Opel parts catalogue (catalogue number: 45 06 154 / part number: 9201697). Sealing plugs are determined for one-off use.

Remove

1. 1. Remove both cylinder head covers

Important. Collect fuel in a suitable container, block oil channels with rags.

2. 2. Remove oil leak line (1), cylinders 1, 3 and 5 • Unscrew 4x banjo bolt • Remove 4x gasket

Important. Collect fuel in a suitable container, block oil channels with rags.

3. 3. Remove leaked oil line (1), cylinders 2, 4 and 6 • Unscrew 4x banjo bolt • Remove 4x gasket

Install

4. 4. Install oil leak line, cylinders 1, 3 and 5 • Replace 4x gasket • Tighten 4x banjo bolt – To camshaft housing 20 Nm – To injector 20 Nm
5. 5. Install oil leak line, cylinders 2, 4 and 6 • Replace 4x gasket • Tighten 4x banjo bolt – To camshaft housing 20 Nm – To injector 20 Nm
6. 6. Attach both cylinder head covers
