Camshafts Opel Vectra C

DOHC Diesel Engine 2 illustrations

Camshafts

1. Tooth flank clearance compensator
2. Camshaft pulley - exhaust
3. Camshaft pulley - inlet

The inlet camshaft drives the exhaust camshaft by means of a spur gear. Thanks to this design, it has been possible to keep the width of the camshaft housing compact. For detection of "cylinder 1 TDC" a dot is marked (arrow) on the spur gear of each camshaft - these dots must line up.

Camshaft Housing

Camshafts

1. Camshaft housing - cylinders 1-3-5
2. Camshaft housing - cylinders 2-4-6

Arrow is pointing to engine timing side
