Special Tools (Z 17 DTH) Opel Combo C

DOHC Diesel Engine 48 illustrations
KM-161-BBearing Puller
Differential inner ring and rollers
KM-301Measuring Bridge
To measure piston projection
KM-313Slide Hammer
To remove axle shafts in conjunction with KM-902
KM-412-AEngine Overhaul Stand
To hold removed engine
KM-412-11-BAdapter
To hold engine in conjunction with KM-412
KM-412-34Adapter
To hold engine in conjunction with KM-412
KM-427Installer/remover
KM-468-BHolding Wrench
To counterhold wheel hub when installing axle nut
KM-470-BAngular Torque Wrench
Tightening screwed joints with tightening angle
KM-471Adapter
To check pressurised cooling system in conjunction with cooling system tester
KM-507-CRemover
Pressing out the tie rod heads
MKM-558-10Closure Cap
Brake fluid reservoir
MKM-571-BDial gauge
MKM-596-ATemperature measuring instrument
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolts
MKM-610Torque Wrench 1/2" drive
Range 30 – 130 Nm / 22 – 96 lbf. ft.
MKM-611Torque Wrench 3/8" drive
Range 10 – 60 Nm / 7 – 44 lbf. ft.
KM-652Locking Device
To lock flywheel or drive disc
KM-656Installer
Oil seal ring
Crankshaft / camshaft
KM-658Installer
Installation of the crankshaft seal ring
MKM-669Torque Wrench 1/2" drive
Range 50 – 300 Nm / 37 – 221 lbf. ft.
KM-717Removing Pliers
To remove wiring harness plug for glow plugs
KM-796-ARemover
To open fuel system quick-release fittings
KM-812Undo high pressure union nuts, line spanner
MKM-883-1Engine Bridge
To remove/install engine damping blocks
KM-902Remover
To remove axle shafts in conjunction with KM-313
KM-904Base Frame
Removing and installing engine with transmission
KM-956-1Holding Wrench
Counterholding the belt pulley/crankshaft
KM-2358Wire Cable
To suspend engine
KM-6015Closure Plugs
Sealing the fuel lines
(d = 10 mm)
KM-6090Valve compressor
Adjusting valve clearance
KM-6092Locking Tool
Removing/installing exhaust camshafts
KM-6098Remover/Installer
Removing/installing injection lines
KM-6156Holding Wrench
Counterholding camshaft pulley in conjunction with KM-956
KM-6168Centring Tool
To remove and install front axle in conjunction with KM-904
KM-6181Fixing, steering play
Steering intermediate shaft adjustment
KM-6182-1Pliers, straight
Removal/installation of compact clamps
KM-6182-2Pliers, curved
Removal/installation of compact clamps
KM-6182-3Pliers, flexible shaft
Removal/installation of compact clamps
KM-6347Bracket
Holding the camshaft sprockets to release them
Tightening the fastening bolts in conjunction with KM-956-1
KM-6357Installer
Installing the sheath for the injector nozzle in the cylinder head
KM-6358Fixing tool
Aligning the injector nozzles
KM-6394Engine/Transmission Mount
Fixing of engine/transmission to front axle body
KM-6602Remover
To remove belt pulley from high pressure pump in conjunction with KM-6603
KM-6603Holding Wrench
To hold the high pressure pump belt pulley when releasing and tightening the retaining nut. Removing the belt pulley in conjunction with KM-6602.
MKM-J-6459-BTorque Wrench 3/8" drive
Range 0 – 11 Nm / 0 – 7 lbf. ft.
KM-J-37228Separation Tool
To disconnect oil pan
KM-J-45000Remover
Removing various seal rings
