Crank Drive, Cylinder Block — Opel Combo C (2002-2011)

Crank Drive, Cylinder Block Opel Combo C

Engine				Z 13 DT, Z13DTJ
Piston diameter
	Standard dimension
		Index A	mm	69.520 - 69.530
		Index B	mm	69.530 - 69.540
		Index C	mm	69.540 - 69.550
	Oversize		mm	0.40 1)
Piston clearance			mm	0.10
Piston projection			mm	0.028 - 0.327
Piston pin
	Bearing			floating in con-rod and piston
	Length		mm	56.40 - 56.80
	Diameter		mm	22.982 - 22.987
	Clearance
		in piston	mm	0.003 - 0.014
		in con-rod	mm	0.003 - 0.019
Piston
	Piston pin boss diameter		mm	22.990 - 22.996
	Weight difference		g	+/- 8
Piston rings
	1st compression ring
		Height	mm	2.00
		Vertical play	mm	0.09 - 0.13
		Gap	mm	0.20 - 0.30
	2nd compression ring
		Height	mm	1.50
		Vertical play	mm	0,04 - 0,08
		Gap	mm	1.00 - 1.50
	Oil scraper ring
		Height	mm	2.00
		Vertical play	mm	0,03 - 0,07
		Gap	mm	0.25 - 0.50

Engine			Y 13 DT, Z 13 DT, Z 13 DTJ
Piston projection			Thickness of cylinder head gasket	Cylinder head gasket code
Dimension
	0.028 - 0.127	mm	0.67 - 0.77	no hole
	0.128 - 0.227	mm	0.77 - 0.87	one hole
	0.228 - 0.327	mm	0.87 - 0.97	two holes

Engine				Y 13 DT, Z 13 DT, Z 13 DTJ
Axial clearance			mm	0.055 - 0.265
Main bearing clearance			mm	0.026 - 0.050
Main bearing journal diameter
		Class A	mm	50.994 - 51.000
		Class AM	mm	50.867 - 50.867
		Class B	mm	50.988 - 50.994
		Class BM	mm	50.861 - 50.867
		Class C	mm	50.982 - 50.988
		Class CM	mm	50.855 - 50.861
Main bearing journal undersize			mm	0.127
Bearing bore diameter in cylinder block
		Class A	mm	54.710 - 54.714
		Class B	mm	54.714 - 54.718
		Class C	mm	54.718 - 54.722
Main bearing shells
		pink	mm	1.836 - 1.841
		blue	mm	1.841 - 1.846
		yellow	mm	1.846 - 1.851
		brown	mm	1.899 - 1.904
		green	mm	1.904 - 1.909
		black	mm	1.909 - 1.914
Crankshaft axial friction washer
	Class R		mm	2.310 - 2.360
	Class RM		mm	2.437 - 2.487
	Oversize		mm	0.127 2)

Engine			Y 13 DT, Z 13 DT, Z 13 DTJ
Con-rod bearing clearance		mm	0.03 - 0.062
Con-rod bearing diameter
	Class A	mm	42.591 - 42.600
	Class AM	mm	42.464 - 42.473
	Class B	mm	42.582 - 42.591
	Class BM	mm	42.455 - 42.464
Diameter of hole in con-rod base		mm	45.734 - 45.744
Diameter of hole in con-rod boss		mm	23.006 - 23.012
Con-rod bearing shells
	red	mm	1.546 - 1.552
	blue	mm	1.550 - 1.556
	brown	mm	1.610 - 1.616
	black	mm	1.614 - 1.620

) Oversize refers to piston with Index A

) Oversize relates to class R
