| 1 | Air cleaner housing |
|---|---|
| 2 | Hot film mass air flow meter |
| 3 | Air intake hose |
| 4 | Air intake manifold |
| 5 | Upper charge air pipe |
| 6 | Charge air hose |
| 7 | Charge air hose |
| 8 | Intercooler |
| 9 | Charge air hose |
| 10 | Lower charge air pipe |
| 11 | Centre charge air pipe |
| 12 | Resonator/Air intake pipe |
| 13 | Connecting hose |
Note. Any possible contamination (grease, oil, etc.) must be cleaned from hoses and connections prior to assembly.
Strict observance of a torque of 3.5 Nm / 2.6 lbf. ft. must be ensured when tightening the hose clamps.
Caution!
Only if the hose clamps are correctly tightened to the specified tightening torque, can sealing of the intake system and thereby operational safety be ensured.
