Replacing Ribbed V-Belt Guide Roller Opel Combo C

Remove

1. 1. Raise vehicle all the way
2. 2. Remove right engine splash guard • Unscrew 3 bolts (1) • Remove body-bound rivet (arrow)

3. 3. Remove ribbed V-belt • Tension ribbed V-belt tensioner in direction of arrow using s KM-913-A at tension roller bolt • Remove ribbed V-belt

Note. Note ribbed V-belt's direction of travel

4. 4. Remove ribbed V-belt guide roller (2) • Remove bolt

Install

5. 5. Install ribbed V-belt guide roller • Tighten bolt 38.2 Nm
6. 6. Install ribbed V-belt • Tension ribbed V-belt tensioner in direction of arrow using KM-913 via retaining bolt (1) and position ribbed V-belt – I. Ribbed V-belt without AC – II. Ribbed V-belt with AC

Note. Note ribbed V-belt's direction of travel

7. 7. Install right engine splash guard • Tighten 3 bolts • Install body-bound rivet
8. 8. Lower vehicle all the way
