Replace Oil Pressure Switch Opel Meriva A

Remove

1. 1. Detach ribbed V-belt
2. 2. Detach compressor • Unscrew 3x bolt (1) • Place to one side

3. 3. Place collecting basin underneath
4. 4. Remove oil pressure switch • Disconnect wiring harness connector. – Push back heat shield • Unscrew oil pressure switch

Install

5. 5. Install oil pressure switch • Tighten oil pressure switch 20 Nm • Connect wiring harness plug – Push on heat shield
6. 6. Attach compressor • Tighten 3x bolts 22 Nm
7. 7. Install ribbed V-belt
8. 8. Lower vehicle all the way
9. 9. Check engine oil level and correct if necessary.
10. 10. Close bonnet
