Coolant Hose Illustration Opel Meriva A

Note. Assignment of coolant hose work operation numbers

1. 1. J601600 - Connecting hose between radiator and coolant expansion tank
2. 2. J601100 - Upper radiator hose elbow
3. 3. J809300 - Fuel/air mixture pre-heating delivery hose
4. 4. J809310 - Fuel mixture pre-heating return hose
5. 5. J601910 - Heat exchanger feed hose
6. 6. J601920 - Heat exchanger return hose
7. 7. J601200 - Lower radiator hose elbow
