Replace Right Engine Damping Block Opel Meriva A

Remove

1. 1. Open bonnet
2. 2. Remove air cleaner housing
3. 3. Raise vehicle
4. 4. Detach ribbed V-belt cover • Unscrew 3 bolts (1) • Remove body-bound rivet (arrow)

5. 5. Attach KM-6394 (1) • Attach KM-6394 to left of front axle body – Slide brackets (2) and (3) inwards as far as they will go • Attach KM-6394 to right of front axle body – Slide bracket (4) from inside to outside as far as it will go – Slide bracket (5) from outside to inside as far as it will go • Tighten 8 bolts

6. 6. Insert locating pins (1) upwards into front axle body • Install 2x securing split pins

7. 7. Install support • To KM-6394 – Adjust bracket (2) for support • Screw on nut (1)
8. 8. Adjust 3x support • Transmission side • Engine timing side – Tighten nuts (1)

Note. Turn spindles until mounts (3) are positioned at the guide journals free of play.

Note. Insert journal of the support in the bore of the cylinder block without play (arrow).

9. 9. Lower vehicle
10. 10. Remove right engine damping block • Undo engine bracket adapter – Unscrew 2x bolts (1) • Loosen engine damping block – Unscrew 2 bolts

Install

11. 11. Fit right engine damping block • Fasten engine bracket adapter – Replace 2x bolt – Tighten 2 bolts – Tightening torque 60 Nm + 30° – 45° • Fasten engine damping block – Tighten 2 bolts – Tightening torque 40 Nm
12. 12. Raise vehicle
13. 13. Detach engine timing side support
14. 14. Remove KM-6394 • Undo 8x bolts
15. 15. Attach ribbed V-belt cover • Screw in 3 bolts • Install clip
16. 16. Lower vehicle
17. 17. Install air cleaner housing
18. 18. Close bonnet
