Replace Engine Damping Block (Rear) Opel Meriva A

Remove

1. 1. Open bonnet

Important. In vehicles with ESP - the steering angle sensor loses its basic settings every time the battery is disconnected and has to be recalibrated.

2. 2. Disconnect battery
3. 3. Raise vehicle
4. 4. Detach shift guide • Unclip retaining clamp (2) • Push shift guide (3) to side • Remove rubber damper
5. 5. Remove rear reaction member (4) • Unscrew 3 bolts (1)

Note. Note differing bolt lengths!

Install

6. 6. Install rear reaction member • Tighten 2x bolts on transmission 80 Nm + 45°– 60° – Use new bolts • Tighten screw connection to reaction member bracket 80 Nm
7. 7. Attach shift guide • Insert rubber damper • Clip in retaining clamp
8. 8. Lower vehicle
9. 9. Connect battery
10. 10. Calibrate steering angle sensor • Turn on ignition

Note. Turn the steering wheel once from the right stop to left stop.

11. 11. Program volatile memory
12. 12. Close bonnet
