| No. | Designation | Note | Mounting | Tightening torque |
|---|---|---|---|---|
| 1 | Rear engine damping block | 2x bolts | 80 Nm | |
| Screw connection | 55 Nm | |||
| 2 | Rear engine damping block bracket | Screw connection | 55 Nm | |
| 3 | Left engine damping block | Remove battery support. Attach KM-6394 Detach left engine damping block from engine damping block support Detach engine damping block support from transmission Remove left engine damping block | 4x bolts | 20 Nm |
| Left engine damping block support | 3x bolts at transmission | 35 Nm | ||
| 4 | Front engine damping block | 2x bolts | 60 Nm | |
| Screw connection | 55 Nm | |||
| 5 | Right engine damping block | Remove air cleaner housing Attach KM-6394 | 2x bolts | 35 Nm |
| 6 | Right engine damping block bracket | 2 new bolts | 65 NM+ 45° + 15° |
- 1. Use of special tools:
Note. When replacing the left and right engine damping blocks, the engine must be supported with KM-6394 .
- 2. Raise vehicle
- 3. Remove right engine splash guard
- 4. Attach KM-6394 (1) • Position KM-6394 on left on front axle body – Push brackets (2) and (3) inwards to the stop • Position KM-6394 on right on front axle body – Push bracket (4) from the inside outwards to the stop – Push bracket (5) from the outside inwards to the stop • Tighten 8 bolts
- 5. Insert dowel pins (1) upwards into front axle body • Install 2x split pin retainers
- 6. Install support • To KM-6394 – Adjust bracket (2) for support • Screw on nut (1)
- 7. Install 3x supports • Transmission side • Engine timing side – Tighten nuts (1)
Note. Turn spindles until mounts (3) are positioned at the guide journals free of play.
Note. Insert support journals in cylinder block hole free of play (arrow)
- 8. Lower vehicle
- 9. Replace Engine Damping Block, Left and/or Engine Damping Block, Right
- 10. Raise vehicle
- 11. Detach engine timing side support
- 12. Remove KM-6394 • Undo 8x bolts
- 13. Attach ribbed V-belt cover • Screw in 3x bolt • Install clip
- 14. Lower vehicle
