The new Z 17 DTR diesel engine is fitted with bucket tappets. For this reason, the procedure for adjusting the valve clearance has changed.
Procedure
1. Check all valves with a feeler gauge (1) and note down the valve clearances.
2. Calculate how much compensation is required for all the valves
| Permissible clearance for intake valves: | 0,4 ± 0,05 mm | |
|---|---|---|
| Permissible clearance for exhaust valves: | 0,4 ± 0,05 mm |
3. Remove the camshafts.
4. Replace the bucket tappets in question.
| Note: | ||
|---|---|---|
| Bucket tappets are available in 35 different thicknesses. The thicknesses vary from 3.46 mm to 4.14 mm in 0.02 mm stages. | ||
| The thickness is stamped on the inside of the bucket tappet. The two-digit figure after the decimal point is given. | ||
| Examples: | 3.46 mm = (46) | |
| 3.80 mm = (80) | ||
| 4.14 mm = (14) | ||
Illustration L0019300 shows, by way of example, the position of the mark on a bucket tappet with a thickness of 3.70 mm .
5. Install the camshafts.
6. Check the adjusted valves.
• Service: The valve clearance must be checked every 150,000 kilometres.
