Remove
Important. During the whole operation, it is crucial to carry the work out in a clean environment. Dirt around the metering device is to be avoided. Even small contaminations, which can not be seen with the naked eye, can lead to severe problems affecting engine performance. Particles sized 0.3 mm can already prove to be critical. Do not wear gloves. Do not install a metering device that had been previously dropped. Remove battery terminal after fault finding. Before replacing the metering device, wait a few minutes to avoid the system self-starting.
- 1. Open bonnet
- 2. Disconnect battery • Remove ground cable – Slacken nut
- 3. Raise vehicle by its full height
- 4. Unclip wiring harness (3) from bracket
- 5. Disconnect wiring harness plug of the metering device • Unclip wiring harness connector (4)
- 6. Remove metering device (2) • Unscrew 2x bolts (1)
- 7. Take out metering device
- 8. Take out seal ring • Take out seal ring (1) from the high pressure pump
- 9. Clean sealing surface
- 10. Check 2X fuel feed drilling (arrow) for any dirt contamination
Install
- 11. Install new seal ring • Smear seal ring (1) with engine oil and install in the high pressure pump – Ensure correct seating
- 12. Insert metering device • Smear clean engine oil onto the O-Ring (1) of the metering device
- 13. Install metering device • Ensure correct seating of the metering device • Tighten 2x bolt 10 Nm
- 14. Re-connect wiring harness plug of the metering device
- 15. Clip wiring harness into bracket
- 16. Lower vehicle by its full height
- 17. Connect battery • Attach negative clamp to ground terminal – Tighten nut
- 18. Program volatile memories
- 19. Reset adaptives of the high pressure pump withTECH 2 • Programming • Confirm pump replacement with "Yes"
- 20. Carry out check for metering device leaks • Actuator test • Carry out fuel leakage test
- 21. Visual check • Check for metering device fuel leaks
- 22. Close bonnet
