Remove
- 1. Raise vehicle by its full height
- 2. Detach lower engine cover and right engine splash guard
- 3. Remove ribbed V-belt (1) • Mark direction of rotation • Apply tension clockwise to tensioner at tension roller bolt (arrow) • Lock tensioner with KM-6130 (2)
Install
- 4. Insert ribbed V-belt • Observe rotational direction of ribbed V-belt • Position ribbed V-belt – I. Ribbed V-belt routing without air conditioning – II. Ribbed V-belt routing with air conditioning • Apply tension to ribbed V-belt tensioner clockwise at the tension roller bolt • Remove KM-6130
- 5. Install lower engine cover and right engine splash guard
- 6. Lower vehicle by its full height
