Terminal Assignment Opel Calibra I

Terminal Assignment

Terminal Assignment of Control Unit

1. X13 Diagnostic Link 16P (Astra-F) X13 Diagnostic Link 10P (Calibra) 29 Ground (Terminal 31)
2. Ground (Terminal 31) 30 P46 Sensor-Knocking Control (Ground)
3. K85 Control Unit-Automatic Transmission 42P 31 P47 Sensor-Camshaft
4. K85 Control Unit-Automatic Transmission 42P 32 P47 Sensor-Camshaft (Ground)
5. Odometer Signal 33 P44 Air Mass Meter

1. K85 Control Unit-Automatic Transmission 42P 34 K60 Relay-Compressor, AC (Ground)
2. Ground (Terminal 31) 35 K43 Relay-Injection Unit, Fuel
3. P29 Temperature Sensor-Intake Manifold 36 P32 Sensor Oxygen Exhaust, heated
4. S109 Switch-Revolution Acceleration 38 L2 Ignition Coil-Direct Ignition (Ground)
5. P32 Sensor Oxygen Exhaust, heated 39 L2 Ignition Coil-Direct Ignition (Ground)
6. Ground (Terminal 31) 40 Y7 Injection Valve 4-Fuel (Ground)
7. P46 Sensor-Knocking Control 41 Y7 Injection Valve 2-Fuel (Ground)
8. P47 Sensor-Camshaft 42 Y7 Injection Valve 1-Fuel (Ground)
9. P44 Air Mass Meter (Ground) 43 Y7 Injection Valve 3-Fuel (Ground)
10. Ground (Terminal 31) 44 M33 Actuator-Idle Speed
11. P35 Impulse Sensor-Crankshaft 45 Y18 Solenoid Valve-Exhaust Gas Recirculation
12. Ignition ON (Terminal 15) 46 M33 Actuator-Idle Speed (Ground)
13. P34 Potentiometer-Throttle Valve 47 Y34 Solenoid Valve-Tank Ventilation (Ground)
14. Ground (Terminal 31) 48 P32 Sensor Oxygen Exhaust, heated (Ground)
15. K85 Control Unit-Automatic Transmission 42P 49 K43 Relay-Injection Unit, Fuel (Ground)
16. U14 Display-Clock (Astra-F) U15 Display-TID (Astra-F) U16 Display-MID (Astra-F) U2 Board Computer (Calibra) 50 Y15 Solenoid Valve Secondary Air Induct
17. X13 Diagnostic Link 16P (Astra-F) X13 Diagnostic Link 10P (Calibra) 52 H30 Telltale-Engine (Ground)
18. S20 Switch ASM-Pressure 53 Y19 Solenoid Valve-Change Manifold
19. P35 Impulse Sensor-Crankshaft (Ground) 54 K44 Relay-Fuel Pump (Ground)
20. P34 Potentiometer-Throttle Valve 55 Battery Voltage (Terminal 30)
21. P30 Temperature Sensor-Coolant
