Special Service Tools Opel Corsa D

DOHC Petrol Engine 56 illustrations
CH-47658Clamping too
To remove the fastening nuts of the tie rod ends
CH-48373Fixture engine / transmission / front axle
To remove, install and fix in position the engine, transmission and front axle in conjunction with KM-904 and the hydraulic jack
CH-48375Adapter
To attach the support from EN-46750 on the vehicle
DT-48489Special socket, width: 36
To loosen and tighten the drive shaft retaining nuts
EN-48375Bonnet support
To support the bonnet in conjunction with the support frame EN-46750
EN-48488Torx E14 chuck key
To release the ribbed V-belt tensioner
KM-161-BPusher tool
To press out the tie rod end from the axle knuckle
KM-301Measuring bridge
To check piston projection
KM-313Slide Hammer
Remove axle shafts in conjunction with KM-902
KM-412-AEngine Overhaul Stand
To hold the removed engine
KM-412-31Engine adapter
To hold engine in conjunction with KM-412-A
KM-422Installer
To press seal ring in camshaft
KM-427Remover, installer
To install guide pins into engine block
KM-468-BHolding Wrench
Counterhold wheel hub when fitting axle nut
KM-470-BAngular Torque Wrench
To tighten cylinder head bolts
KM-471Adapter
To check pressurised cooling system in conjunction with cooling system tester
KM-498-BOil Pressure Manometer
To check engine oil pressure in conjunction with KM-135
KM-527-ASetting rod
Gear stick catch
MKM-558-10Closure cap
Close brake fluid reservoir when opening brake system
MKM-571-BDial gauge
To check various components
MKM-596-ATemperature gauge
To measure oil temperature
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolts
KM-609Electronic Kit I
To diagnose electrical and electronic systems
MKM-610Torque Wrench, 1/2"
Range 30 – 130 Nm
MKM-611Torque Wrench, 3/8"
Range 10 – 60 Nm
KM-652Flywheel Locking Device
To lock flywheel or drive disc
MKM-667Pressure and Vacuum Pump
To check for leaks in vacuum unit
MKM-669Torque Wrench, 1/2"
Range 50 – 300 Nm
KM-796-ADismantler
To open quick-release fittings for fuel system
KM-840Remover
Removing the valve stem seal
KM-845Suction Device
To remove the hydraulic valve lifters
KM-902Remover
Remove axle shafts in conjunction with KM-313
KM-904Base Frame
To remove and install various vehicle components with additional adapters
KM-956-1Grip
To hold camshaft pulleys when loosening/tightening the fastening bolts. Use with KM-6347
KM-958Installer
Installing the valve stem seal
KM-2358Wire ropes
Hitching engine
KM-6009Remover/Installer
To remove/install ignition module
MKM-6086Automatic Valve Spring Lever
Removing/installing valve springs and valve cotters
KM-6179Remover/Installer
Removal/installation of oxygen sensor in manifold using MKM-611
KM-6333Fixing rod
Fixing the toothed belt tensioning device
KM-6340Locking Tool
Fixing the camshaft sprockets for checking and adjusting the timing
KM-6349Fixing rod
To fix the ribbed V-belt tension roller
KM-6351Assembly Sleeves
Installation of front crankshaft seal ring (DOHC-I engine, 3rd gen)
KM-6361Feeler gauges
Measuring the valve clearance (DOHC-I engine, 3. Gen.)
KM-6363Spark Plug Key
Removal and installation of spark plugs (DOHC-I engine, 3. Gen.)
MKM-6600-1Torque wrench 4-40 Nm
Small torque wrench with narrow range for use in restricted spaces, together with MKM-6600-100, MKM-6600-200 and MKM-6600-300
MKM-6600-2Torque wrench 20-120 Nm
Large torque wrench with wide torque range for use in restricted spaces, together with MKM-6600-100, MKM-6600-200 and MKM-6600-300
MKM-6600-100Torx bit and socket set
Sizes: E8, E10, E11, E12, E14, E16, E18, E20, E22, E24 for use in constricted spaces, together with MIM-6600-1 and MKM-6600-2
MKM-6600-200Box spanner socket set
Sizes:10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27 for use in constricted spaces, together with MIM-6600-1 and MKM-6600-2
MKM-6600-300Open-ended spanner socket set
Sizes:10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27 for use in constricted spaces, together with MIM-6600-1 and MKM-6600-2
KM-6623Installer
Installation of crankshaft seal ring, transmission side
KM-6624Remover
Removal of crankshaft seal ring, transmission side
KM-6625Flywheel Locking Device
Blocking the flywheel, gearbox installed
KM-6628Fixing tool
Fixing the camshaft in TDC position to check and adjust timing
KM-J-34730-91Pressure Tester
To check fuel pressure
KM-J-45000Remover
To remove various sealing rings
