Remove
- 1. Open bonnet
- 2. Remove rear toothed belt cover
- 3. Unclip wiring duct from cylinder head cover
- 4. Detach engine vent pipe (4) from cylinder head cover • Undo quick-release fitting (1) • Unclip line • Remove quick-release fitting (2) from cylinder head cover – Detach locking bracket (3)
- 5. Remove engine vent pipe • Detach vacuum line (4) – Detach 2x cable ties (1) – Open insulation • Detach quick-release fitting (3) from turbocharger intake pipe • Unscrew bolt (2)
Install
- 6. Attach engine vent pipe • Tighten bolt • Attach quick-release fitting to turbocharger intake pipe • Attach vacuum line – Close insulation – Attach 2x cable tie
- 7. Install engine vent pipe • Connect quick-release fitting • Clip in line • Attach engine vent hose to cylinder head cover – Attach locking bracket
- 8. Install rear toothed belt cover
- 9. Close bonnet
