Note. When removing or replacing the right and left engine damping block or their fixings, the engine must be secured against lowering
The rear engine damping block can also be removed and installed without supporting the engine
- 1. Attach engine to corresponding engine transport shackle on engine hoist (1)
Note. The diagram shows removal of the right engine damping block
- 2. Table for engine damping block fixing No. Designation Note Fastening Tightening torque I 1 Rear engine damping block to front axle body New bolt 80 Nm + 45° 2 Rear engine damping block to engine damping block bracket New bolt 80 Nm + 45° 3 Rear engine damping block bracket to transmission 2x new bolts 80 Nm + 45° II 4 Left engine damping block to side member Remove battery support. Remove fuse box Hitch engine up to engine crane. 2 bolts 80 Nm 5 Left engine damping block to left engine damping block bracket 3x new bolts 80 Nm + 45° 6 Left engine damping block support to transmission Remove left engine damping block 3x new bolts to transmission M12: 80 Nm + 30° M10: 60 Nm + 30° III 7 Right engine damping block to right engine damping block bracket Remove air cleaner housing Hitch engine up to engine crane. 2x new bolts 80 Nm + 45° 8 Right engine damping block to right side member Remove air cleaner housing Hitch engine up to engine crane. 3x bolts 60 Nm Right engine damping block bracket to cylinder head and cylinder block Remove air cleaner housing Hitch engine up to engine crane. Remove engine damping block, right hand side 3x bolts 60 Nm
