Measure
Cylinder liner projection – use straight edge and feeler gauge projection should be 0.1 mm.
Difference in height between any two adjacent liners must not exceed 0.03 mm.
Measure
Cylinder liner bore at distance A 20 mm from top of bore in the thrust and axial directions.
If measured value exceeds specification replace cylinder liner:
- 4JA1T/4JA1TC engine – 93.10 mm.
- 4JG2T engine – 95.47 mm.
Caution
Cylinder liner is chrome plated and cannot be re-bored or honed.
If inside of cylinder liner is scored or scorched the cylinder liner must be replaced.
