Engine Control System Description and Operation Opel Agila B

Engine Control and Fuel System - D13A 2 illustrations ~345 words

ECM Registration

The following vehicle information is registered in the engine control module (ECM):

• Fuel injector calibration code.

• Vehicle variant data.

• Mixture control oxygen sensor data (without DPF).

• Engine oil parameter (with DPF).

• Diesel particle filter (DPF) data.

• DPF difference pressure sensor data.

• Catalytic converter data (with DPF).

• Password and secret key code (immobilizer model).

Engine Control System with DPF

Fuel feed line
Fuel return line
Fuel pressure line
1. Air cleaner
2. Mass air flow (MAF) and Intake air temperature (IAT) sensor
3. Turbocharger
4. Intercooler
5. Accelerator pedal position (APP) sensor
6. Brake light switch and brake switch
7. Clutch pedal position (CPP) sensor
8. Boost pressure sensor
9. Camshaft position (CMP) sensor
10. Glow plug
11. Engine coolant temperature (ECT) sensor
12. Crankshaft position (CKP) sensor
13. Fuel injector
14. Fuel temperature sensor
15. Fuel pressure sensor
16. Exhaust gas recirculation (EGR) valve
17. High pressure pump
18. Fuel pressure regulator
19. Fuel filter
20. Fuel pump
21. Fuel tank
22. Vacuum pump
23. Boost pressure solenoid control valve
24. Boost pressure control valve
25. Catalytic converter
26. To engine control module (ECM)
27. Common rail
28. Fuel heater
29. To glow plug control module
30. Oil seperator
31. DPF
32. DPF differential pressure sensor
33. Exhaust gas temperature (EGT) sensor

Engine Control System Description and Operation

Electronic Control System Without DPF
