Special Tools - DOHC Ii (DOHC Engine) Opel Omega B

DOHC Petrol Engine 9 illustrations
KM-135Adapter
To measure engine oil pressure in conjunction with KM-498-B
KM-194-ESpark Plug Key
To remove/install spark plug
KM-235-DInstaller
To install crankshaft needle bearing and seal ring
KM-236-BRemover
To remove joints from steering arm and idler arm
KM-263-BEngine Lifter
To hold/lift the engine
KM-301Gauge Bar
To check piston projection
KM-328-BRemover
To drive out crankshaft needle bearing
KM-412Engine Overhaul Stand
To hold removed engine
KM-412-8-AAdapter
To hold engine in conjunction with KM-412
KM-422Installer
To install seal ring into camshaft carrier
KM-427Remover/Installer
To install guide pins into engine block
KM-469-ARemover / Installer
To remove and install crankshaft seal ring
KM-470-BAngular Torque Wrench
To tighten cylinder head bolts
KM-471Adapter
To check pressurised cooling system in conjunction with cooling system tester
KM-498-BOil Pressure Gauge
To check engine oil pressure in conjunction with KM-135
KM-535Installer
To install crankshaft seal ring in conjunction with KM-635
MKM-571-BDial Gauge
To measure piston projection
MKM-596-ATemperature Gauge
To measure oil temperature, exhaust gas test
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolts
KM-609Electronic Kit I
Diagnosis of electric and electronic systems
MKM-610Torque Wrench, 1/2"
Range 30 – 130 Nm / 22 – 96 lbf. ft.
MKM-611Torque Wrench, 3/8"
Range 10 – 60 Nm / 7 – 44 lbf. ft.
KM-635Installer
To install rear crankshaft seal ring in conjunction with KM-535
KM-652Flywheel Holder
To lock flywheel or drive disc
KM-653-AAdapter
To tension valve spring in conjunction with KM-348
KM-662-CHolding Wrench
To keep the toothed belt drive gear fixed when removing or installing the fastening bolt
MKM-667Pressure and Vacuum Pump
To check vacuum units for leaks
MKM-669Torque Wrench, 1/2"
Range 50 – 300 Nm / 37 – 221 lbf. ft.
KM-693-AAssembly Sleeves
To install front crankshaft seal ring
KM-726-AOil Filter Wrench
To remove/install the oil filter
KM-798Dial Gauge
To measure tooth backlash of balancer shaft unit
KM-835-AInstaller
To install valve stem sealing
MKM-836Remover
To remove spark plug connector
KM-840Remover
To remove valve stem seal
KM-845Suction Device
To remove the hydraulic valve lifters
KM-853Locking Tool
To lock the camshaft sprockets
MKM-874Precision Multimeter
To test electrical/electronic components
MKM-883-1Engine Bridge
Hold/lift engine in combination with KM-883-4-A
MKM-883-4-ASecuring hook
Hold/lift engine in combination with KM-883-1
KM-913-AInstallation Wrench
To tension/relax the ribbed V-belt tension roller
KM-949Measurement Sensor
To measure in conjunction with KM-798
KM-2355Socket Wrench T55
To loosen/tighten cylinder head bolts
KM-2358Engine Lifter Shackles
To remove and install engine
KM-6009Remover/Installer
To remove/install ignition module
KM-6086Automatic Valve Spring Lever
Removal/installation or valve springs and valve keepers
KM-6190Engine / Transmission Holder
To remove/install drive unit
KM-J-26792Checking Spark Plug
To check ignition spark
KM-J-34730-91Pressure Tester
To check fuel pressure
KM-J-37228Separation Tool
To remove one-piece oil pan
