Special Service Tools Opel Vectra B

DOHC Petrol Engine 7 illustrations

Special Service Tools

KM-135Adapter
To measure engine oil pressure in conjunction with KM-498-B
KM-194-BSpark Plug Wrench
To remove/install spark plug
KM-301Gauge Bar
To check piston projection
KM-340-EValve Cutter Set
To cut, correct valve seat
KM-348Valve Spring Compressor
To compress valve spring in conjunction with KM-653
KM-412Engine Overhaul Stand
To receive removed engine
KM-412-8-AAdapter
To hold engine in conjunction with KM-412
KM-422Installer
To press seal ring in camshaft
KM-427Remover/Installer
To drive centring pin in cylinder block
KM-470-BAngular Torque Wrench
To tighten cylinder head bolts
KM-471Adapter
To check pressurised cooling system in conjunction with cooling system tester
KM-498-BOil Pressure Gauge
To check engine oil pressure in conjunction with KM-135
KM-535Installer
To install crankshaft seal ring in conjunction with KM-635
MKM-571-BDial Gauge
To check various components
MKM-596Gauge (no longer available)
To measure the oil temperature
MKM-604-CTorx Bit and Socket kit
To remove/install Torx bolts
KM-609Electronic Kit I
To diagnose electrical and electronic systems
MKM-610Torque Wrench, 1/2" drive
Measuring range 30 - 130 Nm/22 - 96 lbf. ft
MKM-611Torque Wrench, 3/8" drive
Measuring range 10 - 60 Nm/7 - 44 lbf. ft.
KM-635Installer
To install rear crankshaft seal ring in conjunction with KM-535
KM-652Locking Device
To lock flywheel or drive disc
KM-653Adapter
To compress valve spring in conjunction with KM-348
KM-662-BHolding Wrench
To hold toothed belt drive gear when removing and installing fastening bolt
MKM-667Pressure and Vacuum Pump
To check vacuum units for leaks
KM-693Assembly Sleeves
To install front crankshaft seal ring
KM-726-AOil Filter Wrench
To remove/install the oil filter
KM-805Reamer
To ream the valve guide, oversize 0.075 mm
KM-835-AInstaller
To install the valve stem seal
KM-836Remover
To remove the spark plug connector
KM-840Removing Pliers
To remove the valve stem seals
KM-845Suctioner
To remove the hydraulic valve lifters
KM-853Fixing Tool
To lock the camshaft sprockets
MKM-883-1Engine Bridge
To hold/lift the engine
MKM-883-2Adapter Plate
To align engine in conjunction with MKM-883-1
MKM-889Remover/Installer
To remove/install the valve stem seals (cylinder head installed)
KM-904Basic Frame
To remove/install different vehicle components with additional adapters
KM-905Centring Locator (Vectra-B)
To remove/install the front axle body in conjunction with KM-904
KM-913Tensioning Wrench, ribbed V-belt
To tension/relax the ribbed V-belt tension roller
KM-2355Socket Wrench
To loosen/tighten the cylinder head bolts
KM-J-34730-91Pressure Gauge
To check the fuel pressure
