The Vectra-B features the C 22 SEL DOHC engine for the first time. The C 22 SEL is based on the C 20 SEL.
The main differences between the C 22 SEL and the C 20 SEL are:
- increased displacement
- differential with balancer shafts
5.1.1 General
The technical features of the C 22 SEL include:
- 4 valves per cylinder
- distributorless ignition system
- SIMTEC 56.5 engine management system
- knock control
- differential with balancer shafts
C 22 SEL engine specifications
| Capacity | 2198 cm 3 |
|---|---|
| Bore diameter | 86 mm |
| Stroke | 94.6 mm |
| Intake valve diameter | 32 mm |
| Exhaust valve diameter | 29 mm |
| Output/rpm | 104 kW/5200 rpm |
| Torque/rpm | 200 Nm/4000 rpm |
| Compression ratio | 9.6:1 |
| Engine management system | SIMTEC 56.5 |
| Octane number requirement | RON 91/95 |
| Conforms to exhaust emissions regulations | US '83, EEC '93, TRIAS 23 |
Engine Identification
The engine identification is located on the cylinder block surface adjoining the transmission flange.
Differential/balancer Shafts
For significant improvement of the C 22 SEL DOHC petrol engine smooth running characteristics, a differential is featured with balancer shafts.
The purpose of the differential is to considerably reduce forces, including torque, stemming from vibrating piston and con-rod masses impacting the engine bearing in conventional designs.
The differential is positioned in the oil pan area beneath cylinders 2 and 3. A housing is integrated in the bearing bridge for mounting both balancer shafts.
A shrunk-fit gear on the 3rd crank web has a 1:2 ratio to drive the gear for the 1st balancer shaft, which rotates opposite the engine rotational direction at twice the crankshaft speed.
The gear for the 2nd balancer shaft is axially aligned with the 1st and rotates in the opposite direction.
- Shrunk-fit gear on the 3rd crank web
- Gear for the 2nd balancer shaft
- Gear for the 1st balancer shaft
- Balancer piece
5.1.3 Differential/balancer Shafts
Simtec 56.5 Engine Management System
Engine Compartment Survey
The following illustrations depict the individual engine compartment component positioning for the C 22 SEL engine.
- Intake air temperature sensor 4 Throttle valve potentiometer
- Hot film mass air flow meter 5 Crankshaft sensor
- Fuel pressure regulator 6 Idle speed stepper motor
5.1.4.1 Engine Compartment Survey
- Camshaft sensor 4 DIS module
- Knock sensor 5 Tank vent valve
- Coolant temperature sensor
