Front Right Engine Bracket, Remove and Install (Without AC)
Disconnect torque support (1) from both torque support brackets and remove.
Attach engine to Engine Bridge MKM-883-1.
Remove side engine compartment cover.
Disconnect engine damping block fastening nut (2) from front axle body.
Disconnect engine bracket with engine damping block (1) from cylinder block and remove downwards.
Disconnect engine damping block from engine bracket - note installation position.
Connect engine damping block to engine bracket - make sure that lug and recess align - tightening torque 45 Nm / 33.2 lbf. ft.
Connect engine bracket with engine damping block to cylinder block - tightening torque 35 Nm / 25.8 lbf. ft.
Connect engine damping block fastening nut to front axle body - tightening torque 45 Nm / 33.2 lbf. ft.
Install side engine compartment cover.
Release engine from Engine Bridge MKM-883-1 and remove engine bridge.
Connect torque support to both torque support brackets - tightening torque 60 Nm / 44.2 lbf. ft.
