Special Tools (Z 17 DTH) Opel Meriva A

DOHC Diesel Engine 46 illustrations
KM-161-BBearing puller
Inner race and rollers - differential
KM-301Measuring Bridge
To measure piston projection
KM-313Slide Hammer
To remove axle shafts in conjunction with KM-902
KM-412-AEngine Overhaul Stand
To hold removed engine
KM-412-11-BAdapter
To hold engine in conjunction with KM-412
KM-412-34Adapter
To hold engine in conjunction with KM-412
KM-470-BAngular Torque Wrench
Tighten screw connections with further turn angle
KM-471Adapter
Check cooling system under pressure in combination with cooling system tester
KM-498-BOil pressure gauge
Check engine oil pressure together with KM-232
KM-507-CRemover
To press out the tie-rod ends
MKM-558-10Closure Cap
Brake fluid reservoir
MKM-571-BDial gauge
MKM-596-ATemperature gauge
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolts
MKM-610Torque wrench 1/2" drive
Range 30 – 130 Nm
MKM-611Torque wrench 3/8" drive
Range 10 – 60 Nm
KM-652Locking Device
To lock flywheel or drive disc
KM-656Installer
Oil sealing ring
Crankshaft / camshaft
KM-658Installer
Crankshaft seal ring installation
MKM-662-CHolding Wrench
Counterhold the belt pulley/crankshaft
MKM-669Torque wrench 1/2" drive
Range 50 – 300 Nm
KM-717Removing Pliers
To remove wiring harness plug for glow plugs
KM-796-ADismantler
Open fuel system quick fittings
KM-812Line Wrench
Release union nuts on high pressure lines
MKM-883-1Engine bridge
To remove, install engine damping blocks
KM-902Remover
To remove axle shafts in conjunction with KM-313
KM-904Base Frame
To remove and install engine with transmission
KM-956-1Holding Wrench
Counterhold the belt pulley/crankshaft
KM-2358Wire Cable
To suspend engine
KM-6090Valve compressor
Adjustment/valve clearance
KM-6092Locking Tool
Exhaust camshaft removal and installation
KM-6098Remover/Installer
High pressure line removal and installation
KM-6168Centring Tool
To remove and install front axle in conjunction with KM-904
KM-6181Steering play fixing
Steering intermediate shaft adjustment
KM-6182-1Pliers, straight
Removing and installing compact clamps
KM-6182-2Pliers, bent
Removing and installing compact clamps
KM-6182-3Pliers, flexible shaft
Removing and installing compact clamps
KM--6347Bracket
To hold the camshaft sprockets to slacken them
Tighten bolts in connection with KM-956-1
KM-6357Installer
To install the injector nozzle sleeve in the cylinder head
KM-6358Fixing tool
To align the injector nozzles
KM-6394Engine/Transmission Mount
Fixing of engine/transmission to front axle body
KM-6602Puller
To pull off the belt pulley from the high-pressure pump in conjunction with KM-6603
KM-6603Holding Wrench
To hold the belt pulley of the high-pressure pump when slackening and tightening the retaining nut. To pull off the belt pulley in conjunction with KM-6602
MKM-J-6459-BTorque wrench 3/8" drive
Range 0 - 11 Nm
KM-J-37228Separation Tool
To disconnect oil pan
KM-J-45000Remover
Removal of various sealing rings
