Replace Oil Pressure Sensor Opel Meriva A

DOHC Diesel Engine 1 illustration

Remove

1. Remove starter
2. Place collecting basin underneath
3. Remove oil pressure sensor (1) • Disconnect wiring harness connector (2) • Unscrew sensor

Replace Oil Pressure Sensor

Install

4. Install oil pressure sensor • Tighten sensor 20 Nm – Insert with sealing compound • Connect wiring harness plug
5. Install starter
