Special Service Tools Opel Meriva A

DOHC Diesel Engine 61 illustrations
CH-47658Clamping tool
To detach fastening nuts of the tie rod ends
KM-161-BBearing puller
Inner race and rollers - differential
KM-301Measuring Bridge
To measure piston projection
KM-313Slide Hammer
To pull left axle shaft from transmission
KM-412-AEngine Overhaul Stand
To hold removed engine
KM-412-11-BAdapter
To hold engine in conjunction with KM-412
KM-412-34Adapter
To hold engine in conjunction with KM-412
KM-470-BAngular Torque Wrench
Tighten cheese-head screws according to angle°
KM-471Adapter
Check cooling system under pressure in combination with cooling system tester
KM-498-BOil pressure gauge
Engine oil pressure in conjunction with KM-6342
KM-507-CRemover
Pressing out the tie rod heads
MKM-558-10Closure cap for brake fluid reservoir
To seal the brake fluid reservoir
MKM-571-BDial gauge
KM-596-ATemperature gauge
To measure oil temperature
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolt
MKM-610Torque wrench 1/2" drive
Range 30 – 130 Nm
MKM-611Torque wrench 3/8" drive
Range 10 – 60 Nm
KM-652Flywheel Holder
To block the flywheel
KM-655Installer
Oil nozzles - piston cooling
KM-656Installer
Crankshaft/camshaft oil seal ring
KM-657Installer
Oil pump seal ring
KM-658Installer
To install crankshaft rear seal ring
KM-662-CHolding Wrench
Toothed belt drive gear, to release/tighten bolt
MKM-667Pressure and Vacuum Pump
To check for leaks in vacuum unit
MKM-669Torque wrench 1/2" drive
Range 50 to 300 Nm
KM-796-ADismantler
Open fuel system quick fittings
KM-812Line Wrench
To release union nuts on pressure lines
KM-845Suction Device
To remove the cup tappet
MKM-883-1Engine bridge
To remove, install engine damping blocks
KM-902Remover
To remove axle shafts in conjunction with KM-313
KM-904Base Frame
Removing and installing engine with transmission
KM-956-1Grip
To hold camshaft pulleys when loosening/tightening the bolt. Use with KM-6347
KM-2358Wire Cable
To suspend engine
KM-6092Locking Tool
To remove, install exhaust camshaft
KM-6092-10Locating Pin
To fix two-part camshaft sprocket in place when installing camshaft, use in conjunction with KM-6092
KM-6098Remover/Installer
Removing/installing injection lines
KM-6168Centring Tool
To remove and install front axle in conjunction with KM-904
KM-6181Steering play fixing
Steering intermediate shaft adjustment
KM-6182-1Pliers, straight
Removing and installing compact clamps
KM-6182-2Pliers, bent
Removing and installing compact clamps
KM-6182-3Pliers, flexible shaft
Removing and installing compact clamps
KM-6282Remover
To remove drive shafts from wheel flange
KM-6332Protective sleeve
To protect axle shaft seal rings when installing the axle shaft
KM--6347Bracket
To hold camshaft sprockets when loosening/tightening the bolt. Use with KM-956-1
KM-6355Puller
To pull the belt pulley from the high-pressure pump in conjunction with KM-6356
KM-6356Holding Wrench
To hold belt pulley of high pressure pump when loosening/tightening the retaining nut. To tighten belt pulley in conjunction with KM-6355
KM-6394Engine/Transmission Mount
Fixing of engine/transmission to front axle body
MKM-J-6459-BTorque wrench 3/8" drive
Range 0 - 11 Nm
MKM-6600-1Torque wrench 4-40 Nm
Small torque wrench for low torque range, for use in confined spaces in conjunction with MKM-6600-100, MKM-6600-200 and MKM-6600-300
MKM-6600-2Torque wrench 20-120 Nm
Large torque wrench for high torque range, for use in tight spaces in conjunction with MKM-6600-100, MKM-6600-200 and MKM-6600-300
MKM-6600-100Torx socket wrench set
Size: E8, E10, E11, E12, E14, E16, E18, E20, E22, E24, for use in confined spaces in conjunction with MKM-6600-1 and MKM-6600-2
MKM-6600-200Box socket wrench set
Size: 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27, for use in confined spaces in conjunction with MKM-6600-1 and MKM-6600-2
MKM-6600-300Open-end socket wrench set
Size: 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27, for use in confined spaces in conjunction with MKM-6600-1 and MKM-6600-2
KM-6602Puller
To pull off the belt pulley from the high-pressure pump in conjunction with KM-6603
KM-6603Holding Wrench
To hold the belt pulley of the high-pressure pump when slackening and tightening the retaining nut. To pull off the belt pulley in conjunction with KM-6602
KM-6610Holding Wrench
To counterhold the axle shaft nut. To fasten wheel bolts to wheel hub.
KM-J-37228Separation Tool
To disconnect oil pan
KM-J-45000Remover
Removal of various sealing rings
EN-48560Alignment tool
Aligning the injectors
EN-48559Capping tool
Capping the injectors
EN-48558Remover
Removing the wiring harness plug from the sheathed glow plugs
