Replace Ribbed V-Belt Opel Astra H

Diesel Engine 2 illustrations ~119 words

Remove

  1. 1. Open bonnet
  2. 2. Raise vehicle by its full height
  3. 3. Detach the lower engine cover and right engine splash guard
  4. 4. Remove ribbed V-belt • Mark rotational direction of ribbed V-belt • Tension the ribbed V-belt tension roller clockwise (direction of arrow) at bolt (1) • Insert KM-6349 (2)

Install

  1. 5. Insert ribbed V-belt • Position ribbed V-belt Routing of ribbed V-belt with air conditioning (up to MY 08) Routing of ribbed V-belt with air conditioning (from MY 08) Routing of ribbed V-belt without air conditioning. • Remove KM-6349

Note. Note direction of travel

  1. 6. Install lower engine cover and right engine splash guard
  2. 7. Lower vehicle by its full height
  3. 8. Close bonnet
