Engine Mount Assembly (RH Side) Replace Opel Antara I



Engine Mount Assembly (RH Side) Replace

Tools Required

DW110-060 Engine Assembly Support Fixture

Remove

Important: Only lift the engine far enough to take the weight off the transmission front mount assembly, or damage to the mount and lifting equipment failure may occur.

1. Remove the engine dress cover. Refer to Engine Dress Cover Replace .
2. Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replace .
3. Support the engine assembly using the engine assembly support fixture DW110-060.

4. Remove the engine mount adapter retaining bolts from the engine mount support bracket.
5. Remove the engine mount frame side bracket retaining bolt and nuts.
6. Remove the engine mount assembly.

Install

1. Install the engine mount assembly.

Tighten

Tighten the engine mount frame side bracket retaining bolt to 100 N•m (74 lb-ft) and nuts to 90 N•m (66 lb-ft).

Tighten the engine mount adapter retaining bolts to 50 N•m (37 lb-ft).

2. Remove the engine assembly support fixture DW110-060.
3. Install the air cleaner assembly. Refer to Air Cleaner Assembly Replace .
4. Install the engine dress cover. Refer to Engine Dress Cover Replace .
