Oil Pump Assembly Opel Antara I



Oil Pump Assembly Replace

Remove

1. Remove the primary timing chain and crankshaft sprocket. Refer to Primary Timing Chain Replace .
2. Remove the three bolts (1) attaching the oil pump (2).
3. Remove the oil pump assembly.

Disassemble

Important:

There are no serviceable components within the oil pump. Disassemble the pump only to diagnose oil related concern. A disassembled oil pump must not be reused: it must be replaced.

The primary timing chain lower guide is not serviced separately and is part of the oil pump assembly. If it is removed from the pump assembly, the guide and the pump must be replaced.

1. Remove the two bolts (1) attaching the primary timing chain lower guide (2) and remove the guide.

2. Remove the seven bolts (2) attaching the oil pump cover to the oil pump housing (1) and remove the cover from the housing.

3. Remove the inner gerotor ring (1).
4. Remove the outer gerotor ring (2).

5. Remove the clip (1), retaining the oil relief valve cap (2).
6. Remove the cap, spring (3) and plunger (4) from the oil pump housing.
7. Clean the oil pump components with non-corrosive solvent.
8. Dry the oil pump components with compressed air.

Inspect

1. Inspect the oil pump housing for damage.

2. Inspect the oil pump cover for damage.

3. Inspect the inner drive gear for damage. If inner surface damage is found, ensure the crankshaft is also inspected.

4. Inspect the outer driven gear for damage.

5. Inspect the oil pump relief valve components for debris or damage.

6. Inspect the primary camshaft chain lower guide for damage. If replacement of the primary camshaft chain lower guide is required, replace the entire oil pump assembly as the primary camshaft chain lower guide is not serviceable separately.
7. If debris or damage is present within the oil pump, further inspection of all of the engine components is required.

Assemble

Important: As there are no serviceable components within the oil pump, a disassembled oil pump must be replaced.

Install

1. Align the oil pump gerotor with the crankshaft flats and fit the oil pump assembly to the engine block.
2. Align the pump body (2) with the mounting holes in the cylinder block.
3. Install the oil pump bolt (1).

Tighten

Tighten the oil pump attaching bolt to 23 N•m (17 lb-ft).

4. Install the primary timing chain. Refer to Primary Timing Chain Replace .
