Engine Flywheel Replace Opel Antara I

DOHC Petrol Engine 5 illustrations ~258 words

Engine Flywheel Replace

Special Tools

•EN-46106 Flywheel Holding Tool
•KM-470-B Angular Torque Gauge

Remove

  1. Remove the engine assembly. Refer to Engine Assembly Replace .
  2. Remove the transmission. Refer to Transmission Assembly Replace for the AF33-5 transmission.
  3. Remove the starter motor. Refer to Starter Replace .
  4. Install EN 46106 (1) into the starter motor mounting location.
  1. Loosen the eight flexplate attaching bolts (1).
  2. Remove the flexplate holding tool.
  3. Using a suitable permanent marker or paint pen, mark the flexplate assembly (2) to crankshaft relationship.
  4. Remove the eight flexplate attaching bolts and discard.
  5. Remove the flexplate assembly.

Inspect

  1. Inspect the flexplate assembly for the following conditions:
•Stress cracks around the flexplate to torque converter mounting bolt hole locations (1).
•Stress cracks around the flexplate to crankshaft mounting bolt hole locations (2 and 4).

Note: Do Not Repair the Welded Areas That Retain the Ring Gear to the Flexplate. the Flexplate Must Be Replaced.

•Stress cracks around the flexplate to torque converter mounting bolt hole locations (1).
•Damaged or missing ring gear teeth (5).

Note: the Flexplate Ring Gear Is Not Serviced Separately and Cannot Be Repaired. If Found to Be Faulty or Damaged, the Flexplate Assembly Must Be Replaced.

  1. Replace the flexplate assembly as required.

Install

Important: The bolt holes are unevenly spaced to enable flexplate fitment in the one position only.

  1. Place the flexplate assembly (2) in position on the crankshaft.
  2. Install new flexplate attaching bolts (1) and hand tighten.
  1. Install the flexplate holding tool, EN 46106 (1) into the starter motor mounting location.
  2. Install the flexplate attaching bolts.

Tighten Tighten the flexplate attaching bolt to 30 N·m (22 lb ft) and turn the bolt another 45 degrees using KM-470-B.

  1. Remove the flexplate holding tool.
  2. Install the starter motor.
  3. Install the transmission. Refer to Transmission Assembly Replace for the AF33-5 transmission.
  4. Install the engine assembly. Refer to Engine Assembly Replace .
