Engine Front Cover Replace Opel Antara I

DOHC Petrol Engine 16 illustrations ~442 words

Engine Front Cover Replace

Special Tools

•EN-46103 Camshaft Actuator Valve Seal Remover/Installer
•EN-46109 Engine Front Cover Installation Guide Pins
•J-29184 Oil Seal Installer

Remove

  1. Remove the engine assembly. Refer to Engine Assembly Replace
  2. Remove the cylinder head covers. Refer to Camshaft Cover Replacement - Left Side and Camshaft Cover Replacement - Right Side .
  3. Remove the crankshaft pulley assembly. Refer to Crankshaft Balancer Replacement
  1. Remove the camshaft position sensors. Refer to Camshaft Position (CMP) Sensor Replace .
  2. Remove the camshaft position actuator solenoid valves. Refer to Camshaft Position Actuator Solenoid Replace .
  3. Remove the bolt (2), 22 places, attaching the front cover assembly (1).

Note : Only Use the Pry Points and a Bolt in the Jackscrew Hole to Remove the Engine Front Cover.

  1. Loosely install a proper bolt in the jackscrew hole (1).
  2. Using the pry points (2) located at the edge of the front cover and the jackscrew, shear the RTV sealant.
  1. Remove the front cover assembly (1).

Disassemble

  1. Remove the crankshaft front oil seal (1) from the engine front cover (2) using a flat-bladed tool. Discard the seals.
  1. Remove the camshaft position actuator valve oil seals (1) from the engine front cover (2). Discard the seals.
  1. Remove the coolant pump seal (1) from the engine front cover (2) and discard the seal.

Clean

Note : Do Not Use a Sharp or Metal Gasket Scraper to Clean the Sealing Surfaces.

  1. Remove any RTV sealant (1) from the engine front cover using a plastic or wood scraper.
  2. Clean out any debris from the bolt holes.
  3. Clean the front cover with a suitable cleaning solvent.
  4. Dry the front cover with compressed air.

Inspect

  1. Inspect both sides of the engine front cover for the following conditions:
•Damage to the camshaft position actuator valve oil seal bores (1)
•Damage to the bolt (2)
•Damage and/or corrosion to the engine coolant passage (3)
•Dents or damage to the exterior (4)
•Damage to the crankshaft front oil seal bore (5)
•Gouges or damage to the coolant pump sealing surfaces (6)
•Damage to the coolant pump bolt hole threads (7)
  1. Repair or replace the front cover as required.

Assem ble

Note : Do Not Lubricate the Crankshaft Front Oil Seal or Crankshaft Pulley Sealing Surfaces. the Crankshaft Pulley Is Installed into a Dry Seal.

  1. Install a new crankshaft front oil seal (1) into the front cover (2) using the crankshaft front seal installer, J-29184 installer (3) and a suitable hammer.
  1. Install a new camshaft position actuator valve oil seal (1) into the front cover (2) using EN-46103 remover/installer (3) and a suitable hammer.

Install

  1. Install the guide pins, EN-46109 pins (1) into the engine block, 2 places.
  1. Install a new engine front cover to cylinder block seal (1).
  1. Apply the RTV sealant (1) to the front cover.
  1. Place the front cover onto the special tools and slide into position.
  2. Remove the special tools from the cylinder block.
  1. Tighten the engine front cover bolts in the sequence shown to 23 N·m (17 lb ft).
  2. Install any other parts that were previously removed.
  3. Install the engine assembly. Refer to Engine Assembly Replace
