Crankshaft Balancer Replace

Special Tools

Remove

1. Rotate the accessory drive belt tensioner clockwise to reduce the belt tension.
2. While holding the tensioner in the reduced tension position, disconnect the belt.

3. Remove the starter. Refer to Starter Replace .
4. Install EN-46106 tool (1) into the starter motor opening to stop the crankshaft from rotating.

5. Remove the bolt (1) attaching the crankshaft pulley assembly (2) to the crankshaft.

6. Remove the crankshaft pulley assembly (1) from the crankshaft using three legged puller, J-41816 puller (2) or equivalent.

Clean

1. Using a suitable non-corrosive cleaning solvent and a soft bristled parts cleaning brush, clean the crankshaft pulley assembly.
2. Dry the crankshaft pulley assembly using compressed air.

Inspect

1. Inspect the crankshaft pulley assembly for the following fault conditions:

Install

1. Lubricate the crankshaft pulley assembly hub bore.
2. Partially install the crankshaft pulley assembly onto the crankshaft.

Note : to Prevent Damage to the Crankshaft Threads, Fully Install J-41998-B Installer (1) into the Crankshaft Before Pressing the Pulley and Balancer Assembly.

3. Using the crankshaft pulley installer, J-41998-B installer (1), fully install the crankshaft pulley assembly into the crankshaft.

4. Apply LOCTITE 272 or equivalent to the thread of a new crankshaft pulley assembly retaining bolt (1).
5. Install the crankshaft pulley assembly retaining bolt and tighten to 100 N·m (74 lb ft) and turns the bolt another 150 degrees using the KM-470-B gage.
6. Install the starter. Refer to Starter Replace .
7. Install the accessory drive belt.
