Oil Pan Replace Opel Antara I

Oil Pan Replace

Special Tools

EN-46109 Engine Front Cover Installation Guide Pins

Remove

1. Disconnect the negative battery cable.
2. Remove the exhaust front pipe. Refer to Exhaust Front Pipe Replace .
3. Disconnect the oil level sensor connector.
4. Remove the oil filler cap for the proper oil draining.

5. Remove the oil pan drain plug and drain the oil into a suitable container.
6. Remove the oil pan flange-to-transmission retaining bolts.

7. Remove the transfer case mounting bracket retaining bolts.
8. Remove the two long bolts (12 and 13) attaching the rear of the oil pan to the crankshaft rear oil seal housing.
9. Remove the 11 bolts attaching the oil pan to the cylinder block.
10. Using the shear points located at the edge of the oil pan shear the RTV sealant.
11. Remove the oil pan from the cylinder block.

Install

1. Install the guide pins, EN-46109 pins (1) into the oil pan rail bolt hole on each side of the engine block.

2. Place a 3 mm bead (1) of RTV sealant on the cylinder block pan rail and crankshaft rear oil seal housing to oil pan mating surfaces.
3. Position the oil pan onto the cylinder block.
4. Remove the guide pins, EN-46109 pins from the cylinder block.

5. Loosely install the oil pan bolts.
6. Install the oil pan bolts in the sequence shown to.

7. Install the oil pan flange-to-transmission retaining bolts and tighten to 50 N·m (37 lb ft).
8. Install the transfer case mounting bracket retaining bolts.

9. Install the oil pan drain plug and tighten to 25 N·m (18 lb ft).
10. Install the exhaust front pipe. Refer to Exhaust Front Pipe Replace .
11. Fill the oil pan with engine oil.
