Accessory Drive Belt Replace Opel Antara I

Accessory Drive Belt Replace

Remove

1. Remove the engine dress cover. Refer to Engine Dress Cover Replace .
2. Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replace .
3. Remove the right front tyre.
4. Remove the splash shield.

5. Rotate the accessory drive belt tensioner clockwise to reduce the belt tension.
6. While holding the tensioner in the reduced tension position, disconnect the belt.

7. Remove the engine mount assembly. Refer to Engine Mount Assembly (RH Side) Replace .
8. Remove the engine mount support bracket retaining bolts.
9. Remove the engine mount support bracket by moving upward.
10. Remove the accessory drive belt.

Install

1. Position the accessory drive belt.
2. Install the engine mount support bracket.

Tighten

Tighten the engine mount support bracket mounting upper bolts to 90 N•m (66 lb-ft).

Tighten the engine mount support bracket mounting lower bolt to 50 N•m (37 lb-ft).

3. Install the engine mount assembly. Refer to Engine Mount Assembly (RH Side) Replace .
4. Rotate the accessory drive belt tensioner clockwise.
5. While holding the tensioner in the reduced tension position, install the belt.
6. Install the splash shield.
7. Install the right front tyre.
8. Install the air cleaner assembly. Refer to Air Cleaner Assembly Replace .
9. Install the engine dress cover. Refer to Engine Dress Cover Replace .
