Timing Belt System Replace Opel Antara I

Timing Belt System Replace

Tools Required

DW110-060 Engine Assembly Support Fixture

EN-48245 Timing Belt Adjuster - Camshaft Holder

EN-48246 Timing Belt Adjuster - Crankshaft Holder

Remove

1. Disconnect the negative battery cable.
2. Remove the beauty cover. Refer to Beauty Cover Replace .
3. Remove the charge air system hoses and ducts. Refer to Charging Air System Replace .
4. Remove the accessory belt. Refer to Accessory Belt and Tensioner Replace .

Important: Only lift the engine far enough to take the weight off the engine mount assembly, or damage to the mount and lifting equipment failure may occur.

5. Support the engine assembly using the engine assembly support fixture DW110-060.

6. Remove the engine mount damping block. Refer to Engine Mount Assembly (RH Side) Replace .

7. Remove the timing belt upper cover.
8. Remove the accessory belt idler.
9. Remove the tensioner. Refer to Accessory Belt and Tensioner Replace .
10. Remove the crankshaft pulley.
11. Remove the timing belt lower cover.
12. Remove the engine mount bracket.

13. Remove the timing belt tensioner.
14. Remove the timing belt.
15. Remove the camshaft sprocket.

Install

1. Install the engine mount bracket.
2. Install the timing belt lower cover.
3. Install the crankshaft pulley.
4. Install the accessory belt idler.
5. Install the timing belt upper cover.

Tighten

Tighten the engine mount bracket bolts to 45 N•m (33.1 lb-ft).

Tighten the timing belt lower cover bolts to 11 N•m (97.4 lb-in).

Tighten the crankshaft pulley bolts to 34 N•m (25.1 lb-ft).

Tighten the accessory belt idler bolt to 52 N•m (38.4 lb-ft).

Tighten the timing belt upper cover bolts to 11 N•m (97.4 lb-in).
