Transmission Rear Mount Assembly Replace Opel Antara I

Transmission Rear Mount Assembly Replace

Tools Required

DW110–060 Engine Assembly Support Fixture

Remove

Important: Only lift the engine far enough to take the weight off the transmission rear mount assembly, or damage to the mount and lifting equipment failure may occur.

1. Support the engine assembly using the engine assembly support fixture DW110–060.

2. Remove the transmission rear mount–to–bracket through bolt.
3. Remove the transmission rear mount bracket retaining bolts from the transmission.
4. Remove the transmission rear mount bracket.
5. Remove the transmission rear mount retaining bolts from the cradle.
6. Remove the transmission rear mount.

Install

1. Install the transmission rear mount to the cradle.

Tighten

Tighten the transmission rear mount retaining bolts to 90 N•m (66 lb–ft).

2. Install the transmission rear mount bracket to the transmission.

Tighten

Tighten the transmission rear mount bracket retaining bolts to 90 N•m (66 lb–ft).

Note: Before tightening the transmission rear mount through bolt, swing the engine assembly backwards and forwards or from the side to side for the proper alignment.

3. Install the transmission rear mount through bolt.

Tighten

Tighten the transmission rear mount–to–bracket through bolt to 90 N•m (66 lb–ft).
