Accessory Belt and Tensioner Replace Opel Antara I

Accessory Belt and Tensioner Replace

Tools Required

EN-48253 Accessory Belt Remover/Installer

EN-48300 Tensioner Remover/Installer

EN-48952 Tensioner Spring Holding Pin

Remove

1. Remove the air cleaner assembly. Refer to Charging Air System Replace .
2. Raise and suitably support the vehicle.
3. Remove the right front wheel.
4. Remove the engine front shield at the position of right front wheel. Refer to Engine Front Shield Replace .

5. Install the accessory belt remover/installer EN-48253 onto the tensioner lever guide and rotate the tensioner clockwise.
6. Rotate the tensioner fully and simultaneously insert tensioner spring holding pin EN-48952 to the tensioner pin hole.

7. Remove the accessory belt.

8. Remove the tensioner using the tensioner remover/installer EN-48300.

Install

1. Install the tensioner bolt manually by hand.

Note : The tensioner dowel pin (a) is not aligned with the tensioner dowel pin hole (b) at this stage.

Important: Tightening the bolt will damage the bracket and the tensioner dowel pin.

2. Install the accessory belt.

3. Install the accessory belt remover/installer EN-48253 to the tension lever guide and rotate the tensioner counter-clockwise.

Note: The tensioner dowel pin (a) is inserted into the tensioner dowel pin hole (b) at this stage.

4. Install the tensioner using tensioner remover/installer EN-48300.

Tighten

Tighten the tensioner retaining bolt to 48 N•m (35.4 lb-ft).

5. Remove tensioner spring holding pin EN-48952 using by the accessory belt remover/installer EN-48253.
