Removing Audi A4 B6

Mechanical 8 illustrations ~305 words
  1. Lock carrier in service position. See «LOCK CARRIER, MOVING INTO SERVICE POSITION»(ref-197058-S08648360322005101100000) .
WARNINGObserve safety precautions when disconnecting the battery.

See BATTERY DISCONNECT PRECAUTIONS .

See Caution before beginning repairs on the electrical system . See LUBRICATION SYSTEM COMPONENTS, REMOVING AND INSTALLING .

Scheme 386

Scheme 386
Scheme 386

Scheme 387

Scheme 387
Scheme 387

Scheme 388

Scheme 388
Scheme 388

Scheme 389

Scheme 389
Scheme 389

Scheme 390

Scheme 390
Scheme 390

Scheme 391

Scheme 391
Scheme 391

Scheme 392

Scheme 392
Scheme 392

Scheme 393

Scheme 393
Scheme 393
  1. Switch ignition off and disconnect battery Ground (GND) strap.
  2. Remove ribbed belt. See «RIBBED BELT, REMOVING AND INSTALLING»(ref-197058-S42630607092005101100000).
  3. Remove air filter housing (arrows).
  4. Remove bolts -1- and -3-. see scheme 402
  5. Disconnect hose -4- from line of secondary air injection.
  6. Pull out guide tube for oil dipstick -2- from the oil pan (upper part) toward top and swing it forward for removal.
  7. Position 10-222A engine support bridge on bolted flanges of fenders.
  8. Remove eyelet for 2024A engine sling.
  9. Insert bolt -1- in the center hole of 2024A Engine Sling and secure with a cotter pin.
  10. Attach bolt for 2024A engine sling at 10-222A engine support bridge spindle.
  11. Attach 2024A Engine Sling to sling clamps at front and rear of engine. WARNING: Take-up hooks and pins at engine sling must be secured using securing pins (arrows) as shown in illustration.
  12. Slightly pre-tension engine using engine support bridge spindle.
  13. Place engine oil drip tray beneath engine.
  14. Drain engine oil.
  15. Loosen oil filter (arrow) using tension strap; e.g. Hazet 2171-1.
  16. Place VAG1306 Drip Tray beneath engine.
  17. Clamp coolant hoses -2- and -3- using 3094 hose clamps.
  18. Disconnect coolant hoses from oil cooler -1-.
  19. Remove oil cooler.
  20. Disconnect electrical harness connector -2- at Secondary Air Injection (AIR) Pump Motor -V101- -Item 1-.
  21. Remove Secondary Air Injection (AIR) pump at longmember. WARNING: Do not open refrigerant circuit for A/C system.
  22. Remove bolts -1- and -2-.
  23. Unclip refrigerant lines (arrows). see scheme 408
  24. Allow the catch reservoir -3- with connected refrigerant lines to remain hanging in installed position.
