Toothed Belt Cover, Removing and Installing Audi A4 B6

Note. The following list refers to items in see scheme 114.

1. 10 Nm
2. 10 Nm
3. Front coolant pipe Only remove bolts -Item 1- and -Item 2- to remove toothed belt guide Coolant hoses remain connected at coolant pipe
4. Toothed belt guard, front right
5. Toothed belt guard, front left
6. Socket
7. 6 Nm Self-locking Always replace
8. Lower toothed belt cover
9. 10 Nm

Scheme 106
